40 SERIES, 25HP, HST W/ INDUSTRIAL TIRES

TRACTOR MODEL 4025 4035 4035 CAB TYPE 3 CYLINDER, WATER COOLED, DIESEL 3 CYLINDER, WATER COOLED, DIESEL 3 CYLINDER, WATER COOLED, DIESEL ENGINE HP @ RPM 24 35 35 DISPLACEMENT (IN.) 104.5 104.5 104.5 NUMBER OF CYLINDERS 3 3 3 FUEL TANK (GAL.) 7.1 7.1 7.1 DRIVE TRAIN TRANSMISSION HST HST HST NUMBER OF SPEEDS 3 RANGE 3 RANGE 3 RANGE CLUTCH NO NO NO BRAKES WET, MULTI-DISC WET, MULTI-DISC WET, MULTI-DISC PTO TYPE INDEPENDENT INDEPENDENT INDEPENDENT REAR(MID) PTO SPEED 540 540 540 PTO HP 19.1 29.5 29.5 HYDRAULICS TYPE HYDROSTATIC POWER STEERING HYDROSTATIC POWER STEERING HYDROSTATIC POWER STEERING TOTAL HYDRAULIC FLOW (POWER STEERING+IMPLEMENT) 11.5 (4+7.5) 12.6 (4.4+8.2) 12.6 (4.4+8.2) 3-POINT HITCH CAT I CAT I CAT I REAR REMOTE VALVE OPTIONAL (UP TO 2) OPTIONAL (UP TO 2) OPTIONAL (UP TO 2) 3POINT HITCH LIFT CAPACITY (LBS.) @24” BEHIND LIFT POINT @ BALL ENDS 1100 1100 1100 ELECTRICAL BATTERY 12 V, 540 CCA 12 V, 540 CCA 12 V, 540 CCA ALTERNATOR 12 V, 50 A 12 V, 50 A 12 V, 50 A DIMENSIONS OVERALL LENGTH (IN.) 134.88 134.88 134.88 OVERALL WIDTH (IN.) 56.7 56.7 55.6 OVERALL HEIGHT (IN.) 104.06 104.06 104.6 WHEELBASE (IN.) 65.7 65.7 65.7 MINIMUM GROUND CLEARANCE (IN.) 13.1 13.1 13.1 WEIGHT (LBS.) 2970 3164 3551 WHEELS & TIRES IND (FRONT) 25X8.50-14 28X8.50-15 28X8.5-15 IND (REAR) 15-19.5 43X16.00-20 43X16.00-20 LOADER MODEL BBL400 BBL400 BBL400C STANDARD BUCKET SIZE (IN.) 62 62 62 MAXIMUM LIFT HEIGHT (IN.) 104 104 104 DIG DEPTH (IN.) 1.8 1.8 1.8 LIFT CAPACITY TO FULL HEIGHT AT PIVOT PIN (LBS.) 2200 2200 2200 BREAKOUT FORCE (LBS.) 3660 3660 3660 SHIPPING WEIGHT (LBS.) 1007 1007 1007 BACKHOE MODEL BBH400 BBH400 BBH400 STANDARD BUCKET SIZE (IN.) 16 16 16 TYPE SUBFRAME-MOUNTED, QUICK ATTACH SUBFRAME-MOUNTED, QUICK ATTACH SUBFRAME-MOUNTED, QUICK ATTACH MAXIMUM DIG DEPTH (IN.) 92.2 92.2 92.2 DIG FORCE BUCKET (LBS.) 4380 4380 4380 SHIPPING WEIGHT (LBS.) 1270 1270 1270
